Fluke 1524 HANDHELD THERMOMETER READOUT

Product

Home / Product

Category: TEMPERATURE

Model: Handheld Temperature Calibrator and Indicator

Avaibility: AVAILABLE

Call For Price

Datasheet

Description
Specification

PRTs and thermistors: 0.001°

Specifications

Input channels	2
Resolution	PRTs and thermistors: 0.001° thermocouples: 0.01°
Logging	25 readings with statistics15,000 time and date stamped
Sample interval (normal)	1 second (simultaneous measurement)
Typical sample interval (fast mode)*	0.3 seconds
Sensor types	PRTs, RTDs, thermistors, and thermocouples
Statistics	Maximum, minimum, average, standard deviation
Trending	Scale: ± 10 °C (18 °F), ± 1 °C (1.8 °F), ± 0.1°C (0.18 °F), ± 0.01°C (0.018 °F), 10 minutes of real-time data
Power requirements	3 AA alkaline batteries, 12 V dc universal power supply
Size (HxWxD)	96 mm x 200 mm x 47 mm (3.75 in x 7.9 in x 1.86 in)
Weight	0.65 kg (1.4 lb)
Computer interface	RS-232, 9940 I/O ToolKit software included
Safety	EN61010-1:2001, CAN/CSA C22.2 No. 61010.1-04
Environmental conditions for best accuracy: 13 °C to 33 °C (55.4 °F to 91.4 °F)
Millivolt range and accuracy	-10 mV to 75 mV, ± (0.005 % + 5 µV)
Internal reference junction compensation	± 0.2 °C (± 0.36 °F)
Resistance range and accuracy	0 ? to 400 ? ± (0.004 % + 0.002 ?) 200 ? to 500 k? ± (0.01 % + 0.5 ?) 50k? to 500 k? ± (0.03 %)
Temperature coefficient, voltage: -10 °C to 13 °C, +33 °C to 60 °C (14 °F to 55.4 °F, 91.4 °F to 140 °F)	± (0.001 %/°C + 1 mV/°C)
Temperature coefficient, resistance: -10 °C to 13 °C, +33 °C to 60 °C (14 °F to 55.4 °F, 91.4 °F to 140 °F)	0.0008 %/°C + 0.0004 ? (0 ? to 400 ?) 0.002 %/°C + 0.1 ? (0 ? to 50 k?) 0.06 %/°C + 0.1 ? (50 k? to 500 k?)
Excitation current, resistance	1 mA (0 ? to 400 ?) 10 µA (0 ? to 50 k?) 2 µA (50 k? to 500 k?)
