| Channel capacity | Total analog channels | 45 |
| Voltage/resistance channels | 41 |
| Current channels | 5 |
| Digital I/O | 1 (8-bit TTL) |
| Totalizer | 1 |
| Alarm outputs | 6 |
| Trigger input | 1 |
| Sample rate | Fast: 10 channels per second (0.1 seconds per channel) |
| Medium: 1 channel per second (1 second per channel) |
| Slow: 4 seconds per channel |
| Display resolution | 6 1/2 digits |
| Input Module options | 2 rear panel slots ('x' designates slot 1 or slot 2 below). Can be configured for 2 High-Capacity Modules, 2 DAQ-STAQ Multiplexers, or one of each |
| Internal High-Capacity Module configuration | 20 channels per module (x01 - x20) 2 dedicated current channels (x21 - x22) (3- and 4-wire connections require 2 channels) |
| External DAQ-STAQ Multiplexer configuration | 10 PRT/thermistor channels (maximum) 20 mini-jack thermocouple channels (maximum) |
| Math channels | 20 channels |
| Operations: sum, difference, multiply, divide, polynomial, power, square root, reciprocal, exponential, logarithm, absolute value, average, maximum, minimum |
| Triggers | Interval, external (trigger input), alarm, remote (bus), manual, automated test |
| Memory | Scan data RAM | 75,000 readings with timestamp |
| Internal memory | 20 MB |
| Standard interfaces | USB host, USB device, Ethernet 10/100 LAN, RS-232 temperature source control for automated temperature data collection from Fluke Calibration drywells and baths |
| Mains voltage | 100 V setting: 90, to 100 V; 120 V setting: 108, to 132 V; 220 V setting: 198, to 242 V; 240 V setting: 216, to 264 V |
| Mains frequency | 47 Hz to 440 Hz |
| Input protection | 50 V all functions, terminals and ranges |
| Dimensions | Height x Width x Depth | 150 mm x 245 mm x 385 mm (5.9 in x 9.6 in x 15.2 in) |
| Weight | 6 kg (13.2 lb) - typical configuration |
| Shipping Weight | 9.5 kg (20.9 lb) - typical configuration |
| Conformity | CE, CSA, IEC 61010 3rd edition |
