Software programmable immediate start Delay start up to 18 months in advance
Specifications
| GENERAL |
| Start Modes | Software programmable immediate start Delay start up to 18 months in advance |
| Stop Modes | Manual or Timed (specific date and time) |
| Real Time Recording | May be used with PC to monitor and record data in real time |
| Password Protection | An optional password may be programmed into the device to restrict access to configuration options. Data may be read out without the password. |
| Memory | 32,512 readings |
| Trigger Settings | High and Low limits may be set. Once data meets or exceed sets limits, the device will record to memory. Bi-level start and stop triggers can also be programmed. Users can specify the number of readings to take after the device triggers. |
| Reading in Trigger Settings Mode | 6,502 readings |
| Wrap Around | Yes |
| Reading Rate | 1 reading every second up to 1 reading every 24 hours |
| Calibration | Digital calibration through software |
| Calibration Date | Automatically recorded within device |
| Battery Type | Two 3 V high-temperature lithium coin cell battery included; user replaceable |
| Battery Life | 1 years typical (1 minute reading rate at 25 °C) |
| Data Format | Date and time stamped °C, K, °F or °R |
| Time Accuracy | ±1 minute/month at 20 °C to 30 °C (68 °F to 86 °F) (Stand alone mode) |
| Computer Interface | IFC400 OR IFC406 USB docking station and adapter required; 125,000 baud |
| Operating System Compatibility | Windows XP SP3 or later |
| Software Compatibility | Standard Software version 4.2.25.16 or later Secure Software version 4.2.24.16 or later |
| Operating Environment | -20 °C to +125 °C (-4 °F to +257 °F) 0 %RH to 100 %RH, 0.002 PSIA to 100 PSIA |
| IP Rating | IP68 |
| Dimensions (Body) | 0.9 in x 0.7 in dia. 22.9 mm x 17.8 mm dia. |
| Dimensions (Probe) | NanoTemp125-1: 1.0 in x 0.125 in dia. (0.188 in trans. dia.) 25.4 mm x 3.2 mm dia. (4.8 mm trans. Dia.) NanoTemp125-2: 2.0 in x 0.125 in dia. 50.8 mm x 3.2 mm dia. (4.8 mm trans. dia.) NanoTemp125-5: 5.0 in. x 0.125 in dia. 133.35 mm x 3.2 mm dia. (4.8 mm trans. dia.) |
| Weight | NanoTemp125-1: 0.63 oz (18 g) NanoTemp125-2: 0.67 oz (19 g) NanoTemp125-5.25: 0.71 (20 g) |
| Material | 316 Stainless Steel, PEEK |
| Approvals | CE |
BATTERY WARNING: BATTERY WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, RECHARGE, DEFORM, THROW INTO FIRE OR DISASSEMBLE. RISK OF EXPLOSION IF HEATED ABOVE 125 °C (257 °F)
| TEMPERATURE |
| Temperature Sensor | Internal RTD |
| Probe Measurement Range | -200 °C to +260 °C (-328 °F to +500 °F) BODY OF LOGGER CANNOT EXCEED 125 °C |
| Temperature Resolution | 0.01 °C (0.02 °F) |
| Calibrated Accuracy | ±0.1 °C/±0.18 °F (20 °C to +125 °C/68 °F to +257 °F) ±0.3 °C/±0.54 °F (-20 °C to +19.99 °C/-4 °F to +67.98 °F) |
