Software programmable immediate start Delay start up to 18 months in advance
Specifications
| GENERAL |
| Start Modes | Software programmable immediate start Delay start up to 18 months in advance |
| Stop Modes | Manual or Timed (specific date and time) |
| Real Time Recording | May be used with PC to monitor and record data in real time |
| Password Protection | An optional password may be programmed into the device to restrict access to configuration options. Data may be read out without the password. |
| Memory | 65,586 |
| Trigger Settings | High and Low limits may be set. Once data meets or exceed sets limits, the device will record to memory. Bi-level start and stop triggers can also be programmed. Users can specify the number of readings to take after the device triggers. |
| Reading in Trigger Settings Mode | 13,107 readings |
| Wrap Around | Yes |
| Reading Rate | 1 reading every second up to 1 reading every 24 hours |
| Calibration | Digital calibration through software |
| Calibration Date | Automatically recorded within device |
| Battery Type | 3.6V high-temperature user replaceable power cell |
| Battery Life | 1 years typical (1 minute reading rate) |
| Data Format | Date and time stamped °C, K, °F or °R |
| Time Accuracy | ± 4.1 minute/month at 25 C |
| Computer Interface | BLE 2.4 GHz IEEE Std. 802.11 |
| Transmission Distance | 100 m max. outdoors - line of sight unobstructed 30 m max. indoors - typical urban environment |
| Operating System Compatibility | Windows XP SP3 or later |
| Software Compatibility | Standard Software version TBD Secure Software version TBD MadgeTech App |
| Operating Environment | -40 °C to +140 °C (-40 °F to +284 °F) 0 %RH to 100 %RH, 0.002 PSIA to 100 PSIA |
| IP Rating | IP68 |
| Dimensions (Body) | RF140-1: 3.29 in x 0.970 in dia. (83.57 mm x 24.6 mm dia.) RF140-2, 5.25, 7: 3.57 in x 0.970 in dia. (90.68 mm x 24.6 mm dia.) |
| Dimensions (Probe) | RF140-1: 1.1 in x 0.125 in dia. (27 mm x 3.2 mm dia.) RF140-2: 2.0 in x 0.188 in dia. (51 mm x 4.8 mm) RF140-5.25: 5.25 in x 0.188 in dia. (133 mm x 4.8 mm dia.) RF140-7: 7.0 in x 0.188 in dia. (178 mm x 4.8 mm dia.) |
| Weight | 4.2 oz (120 g) |
| Material | 316 Stainless Steel, PPSU |
| Approvals | CE , FCC |
| TEMPERATURE |
| Temperature Sensor | 100 ? Platinum RTD |
| Probe Measurement Range | -40 °C to +140 °C (-40 °F to +284 °F) |
| Temperature Resolution | 0.01 °C (0.02 °F) |
| Calibrated Accuracy | ±0.1 °C/±0.18 °F (20 °C to +140 °C/68 °F to +284 °F) ±0.3 °C/±0.54 °F (0 °C to +19.99 °C/-4 °F to +67.98 °F) ±0.4 °C/±0.72 ºF (-40 °C to -20.01 °C/-40 °F to +-4.02 °F) |
